ISO14443A Mifare reader / writer 13.56mhz rfid NFC desktop encoder sector reading or writing
$40.91
$58.1
Features:• USB keyboard emulation, Plug and Play or Serial Port emulation or as a reader/writer for encoding cards • Can be set to read a specific sector or data of mifare 1k, 4k, ultralight or Ntag203 cards and tags • Auto-detect card and UID or block data as keyboard wedge • Provide API development tool • Update firmware through USB interface without disassembling case • Support Decimal and Hexadecimal ID formats (can be changed by using a configuration software) • Unique serial number for identification • Built-in user data storage space • Able to write URL to memory and users can simply open a webpage with the NFC-enabled mobile phone (Utralight NTAG203) Applications:• Program Development • Printer Login • Library management • Card encoding • NFC tag reading and writing • Student management • Access Control • PC Authentication • ID Identification • Print control • Password Login Specification:Model NumberRD-200-M1Dimension105 x 72 x 16 mm StandardISO14443ASupportMifare 1K S50 Mifare UltraLight Mifare Ntag203 (NFC) Mifare 4K S70 Mifare Classic AT88RF020 66CL160SFrequency13.56MHz read / writespeed106kbit/sBaud Rate9600-115200 bit/sPower SupplyPower supply through USB, 5V / 200mA Operating Distance0~6cm/0~5cm InterfaceUSB and USB virtual COMStatus Indication1pcs LED; 1pcd buzzerOperating Temperature-20℃~ 70℃ Storage Temperature-30℃~ 80℃
